CS149 (2024): Assignment 2

封面来源：@Ge_DaZuo

相关文章：Stanford-CS149-并行计算-Assignment2-任务执行库 - 知乎、CS149 Programming Assignment 2 - Scheduling Task Graphs on a Multi-Core CPU | MizukiCry’s Blog
C++ 并发帮助的文章：std::condition_variable.wait()的用法和设计缺陷带来的坑_condition variable wait-CSDN博客
原始实验材料仓库：stanford-cs149/asst2
我的实现仓库：Livinfly/15-418u15-618uCS149u
任务推荐资料：
C++ Interfaces - abstract class 抽象类介绍
C++ synchronization tutorial 基础的 std::thread, std::mutex, std::condition_variable, std::atomic 使用介绍

环境

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
# 系统版本
uname -a
lsb_release -a
nvidia-smi
cat /proc/cpuinfo
cat /proc/cpuinfo | grep processor | wc -l
# Mac OS
uname -a
sysctl machdep.cpu.brand_string
sysctl hw.physicalcpu
sysctl hw.logicalcpu

OS: Darwin MacBook-Pro.local 24.1.0 Darwin Kernel Version 24.1.0: Thu Oct 10 21:06:57 PDT 2024; root:xnu-11215.41.3~3/RELEASE_ARM64_T6041 arm64
CPU: Apple M4 Pro (14 physicalcpu, 14 logicalcpu)，（10性能和4能效）
GPU: 20 Cores
Memory: 24 GB
Python 3.9.6

（不过不影响，测试同时也在 wsl2 上测试，环境同 asst1）

Part A: Synchronous Bulk Task Launch

完成类似 ispc task 的功能，任务分成三个类的实现。

因为 pthread 要传递函数参数的话，可能要额外再写个包装函数void* wrapper_function(void* arg) return NULL;，再观察到编译 c++ 版本是 c++ 11，决定用 std::thread 实现多线程了。

测试和run_test_harness.py 统一放到最后。

因为核心数是 10 性能 + 4 能效，所以线程数为 10 时的结果会可能更好。（因为不用等能效核的慢任务）

发现，最大困难是明确要求，初版实现基本都有点偏离要求了，写晕了。（不过也就懒得删，放实现仓库了，以 .bak 结尾的 tasksys 文件）

参考其他人的实现，重新搞清楚了要求。

TaskSystemParallelSpawn

固定最大工作线程数，每次在 run 的时候创建，只创建最大工作线程数次。

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
// tasksys.h

#include <atomic>
#include <thread>

class TaskSystemParallelSpawn : public ITaskSystem {
   private:
    int _num_threads;
    std::thread* _threads_worker;
};

// tasksys.cpp

TaskSystemParallelSpawn::TaskSystemParallelSpawn(int num_threads)
    : ITaskSystem(num_threads),
      _num_threads(num_threads),
      _threads_worker(new std::thread[num_threads]) {}

TaskSystemParallelSpawn::~TaskSystemParallelSpawn() {
    delete[] _threads_worker;
}

void TaskSystemParallelSpawn::run(IRunnable *runnable, int num_total_tasks) {
    std::atomic<int> task_id(0);

    auto work = [&task_id, &runnable, &num_total_tasks]() {
        // 可以批量处理，减少原子操作
        // const int BATCH_SIZE = 16;
        while (true) {
            int id = task_id.fetch_add(1);
            if (id >= num_total_tasks) break;
            runnable->runTask(id, num_total_tasks);

            // 可以批量处理，减少原子操作
            // int start_id = task_id.fetch_add(BATCH_SIZE);
            // if (start_id >= num_total_tasks) break;
            // int end_id = std::min(start_id + BATCH_SIZE, num_total_tasks);
            // for (int id = start_id; id < end_id; id++) {
            //     runnable->runTask(id, num_total_tasks);
            // }
        }
    };

    for (int i = 0; i < _num_threads; i++) {
        _threads_worker[i] = std::thread(work);
    }
    for (int i = 0; i < _num_threads; i++) {
        _threads_worker[i].join();
    }
}

TaskSystemParallelThreadPoolSpinning

构建类的时候就创建好最大工作线程（线程池），在类析构的时候才停止工作进程，线程等待的时候，选择 spin，即 while(!condition);。

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
// tasksys.h

#include <atomic>
#include <mutex>
#include <thread>

class TaskSystemParallelThreadPoolSpinning : public ITaskSystem {
private:
    int _num_threads;
    std::thread* _threads_worker;
    // run_info
    bool _end;
    IRunnable* _runnable;
    int _num_total_tasks;
    int _current_task_id;
    std::mutex* _mtx;
    std::atomic<int> _num_done_tasks;
};

// tasksys.cpp

TaskSystemParallelThreadPoolSpinning::TaskSystemParallelThreadPoolSpinning(
    int num_threads)
    : ITaskSystem(num_threads),
      _num_threads(num_threads),
      _threads_worker(new std::thread[num_threads]),
      _end(false),
      _runnable(nullptr),
      _mtx(new std::mutex) {
    auto work = [&]() {
        while (true) {
            IRunnable *runnable = nullptr;
            int task_id;
            _mtx->lock();
            if (_runnable) {
                runnable = _runnable;
                task_id = _current_task_id++;
                if (_current_task_id >= _num_total_tasks) _runnable = nullptr;
            }
            bool is_end = _end;
            _mtx->unlock();
            if (runnable) {
                runnable->runTask(task_id, _num_total_tasks);
                _num_done_tasks.fetch_add(1);
            } else if (is_end) {
                break;
            }
        }
    };
    for (int i = 0; i < _num_threads; i++) {
        _threads_worker[i] = std::thread(work);
    }
}

TaskSystemParallelThreadPoolSpinning::~TaskSystemParallelThreadPoolSpinning() {
    _mtx->lock();
    _end = true;
    _mtx->unlock();
    for (int i = 0; i < _num_threads; i++) {
        _threads_worker[i].join();
    }
    delete[] _threads_worker;
    delete _mtx;
}

void TaskSystemParallelThreadPoolSpinning::run(IRunnable *runnable,
                                               int num_total_tasks) {

    _mtx->lock();
    _runnable = runnable;
    _num_total_tasks = num_total_tasks;
    _current_task_id = 0;
    _num_done_tasks = 0;
    _mtx->unlock();

    while (_num_done_tasks < _num_total_tasks);
}

TaskSystemParallelThreadPoolSleeping

在 TaskSystemParallelThreadPoolSpinning 的基础上，使用 std::condition_variable 降低 spin 带来的开销。

提示可以添加在工作线程没任务做和主线程等待工作线程完成任务这两个阶段。

这里保留了其他实现与调试的注释。

调试过程中，对 std::mutex, std::condition_variable 逐渐有了些感觉。

（不过像什么生产者-消费者模型，只是知道，还没有去实现学习，咕咕）

这里主要原因是，主线程的等待好像用条件变量，会慢不少，所以保留了（我也不再细究这个情况了）

这种多线程并发的程序调试，感觉很大程度还是需要用输出调试来调，有些时候稍微顺序错位一点点在几次测试中可能并不会出错。

有输出可以更加清楚的知道，运行的情况。

比如我保留的注释，让我发现在 super_super_light 测试中，可能在主线程开始等待前，工作线程就做完了等情况。

后面也学着把会被别的线程修改的数据先读到本地，然后在释放锁之后，再做处理。

又可以避免忘记释放锁，也能在后面再使用的时候更加安全。

这里再简单说说我对 std::condition_variable 粗浅认识：

（如有错误，敬请指正，最好附上代码案例）

主要分为 wait(unique_lock, [condition]) 和 notify_one() / notify_all()。

wait(unique_lock, [condition])
需要在 wait() 之前，该线程有获得 / 锁上 unique_lock 这个锁。
到 wait() 的时候，会检测条件是否符合：
- 符合，不会堵塞，继续运行；
- 不符合，会堵塞，等待其他线程唤醒 notify_*()。
  唤醒后再判断条件是否符合，以此类推。
因此，可以等价于 while(!condition) {wait();}。
这里的 wait() 就是事实的堵塞，被唤醒后，继续进行循环条件的判断。
所以，如果恒为真，就不会堵塞，恒为假就永远堵塞。
因此，对于工作线程的 std::condition_variale 只要在最开始执行一次 notify_all()，
然后就会把这一批次执行完了，不需要在内部再反复 notify_*() 了。
notify_one() / notify_all()
随机唤醒一个等待线程 / 唤醒所有等待线程。
notify_*() 和释放当前锁的先后。
从结果上来说是都可以，不过先释放锁，在 notify_*() 可以减少一步竞争锁这一步（大概？）

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
// tasksys.h

#include <atomic>
#include <condition_variable>
#include <mutex>
#include <thread>

class TaskSystemParallelThreadPoolSleeping : public ITaskSystem {
private:
    int _num_threads;
    std::thread* _threads_worker;
    // run_info
    bool _end;
    IRunnable* _runnable;
    int _num_total_tasks;
    int _current_task_id;
    int _num_done_tasks;
    std::mutex *_mtx, *_mtx_done;
    std::condition_variable *_cv, *_cv_done;
}

// tasksys.cpp

TaskSystemParallelThreadPoolSleeping::TaskSystemParallelThreadPoolSleeping(
    int num_threads)
    : ITaskSystem(num_threads),
      _num_threads(num_threads),
      _threads_worker(new std::thread[num_threads]),
      _end(false),
      _runnable(nullptr),
      _mtx(new std::mutex),
      _mtx_done(new std::mutex),
      _cv(new std::condition_variable),
      _cv_done(new std::condition_variable) {
    auto work = [&]() {
        while (true) {
            IRunnable *runnable = nullptr;
            int task_id;
            std::unique_lock<std::mutex> lk(*_mtx);
            _cv->wait(lk, [&]() { return _runnable || _end; });
            if (_runnable) {
                runnable = _runnable;
                task_id = _current_task_id++;
                if (_current_task_id >= _num_total_tasks) _runnable = nullptr;
            }
            bool is_end = _end;
            lk.unlock();
            if (runnable) {
                runnable->runTask(task_id, _num_total_tasks);
                // 需要 lock，不然可能主线程还没开始 wait
                // 这边的通知就已经发出去了（任务特别轻的时候
                // super_super_light）
                _mtx_done->lock();
                _num_done_tasks++;
                // printf("%d\n", _num_done_tasks);

                // 1
                // bool is_done = _num_done_tasks >= _num_total_tasks;
                _mtx_done->unlock();
                // if (is_done) {
                //     // puts("done 0");
                //     _cv_done->notify_one();
                // }
                // 2
                // _cv_done->notify_one();
            } else if (is_end) {
                break;
            }
        }
    };
    for (int i = 0; i < _num_threads; i++) {
        _threads_worker[i] = std::thread(work);
    }
}

TaskSystemParallelThreadPoolSleeping::~TaskSystemParallelThreadPoolSleeping() {
    _mtx->lock();
    _end = true;
    _mtx->unlock();
    _cv->notify_all();
    for (int i = 0; i < _num_threads; i++) {
        _threads_worker[i].join();
    }
    delete[] _threads_worker;
    delete _mtx;
    delete _mtx_done;
    delete _cv;
    delete _cv_done;
}

void TaskSystemParallelThreadPoolSleeping::run(IRunnable *runnable,
                                               int num_total_tasks) {
    // 要先为 wait 获取锁，堵塞后释放

    // 1, 2
    // std::unique_lock<std::mutex> lk_done(*_mtx_done);
    {
        std::unique_lock<std::mutex> lk(*_mtx);
        _runnable = runnable;
        _num_total_tasks = num_total_tasks;
        _current_task_id = 0;
        _num_done_tasks = 0;
    }
    _cv->notify_all();

    // puts("wait");

    // 1
    // _cv_done->wait(lk_done);
    // 2
    // _cv_done->wait(lk_done,
    //                [&]() { return _num_done_tasks >= _num_total_tasks; });
    // 3
    while (true) {
        _mtx_done->lock();
        bool is_done = _num_done_tasks >= _num_total_tasks;
        _mtx_done->unlock();
        if (is_done) break;
    }

    // puts("done 1");
}

测试

~~加测试还是算了，看看测试得了~~

我调试调出比较多问题的就是 super_super_light 了，具体测试的任务，见 tests/README.md，找到适合调试的测试，或试着自己创建测试。

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
// tests/main.cpp

// TODO: do this better
if (j + 1 == num_timing_iterations) {
    printf("[%s]:\t\t[%.3f] ms\n", t->name(), minT * 1000);
    // 更多的信息显示
    // 然而 run_test_harness 需要保持输出格式不能出现太多变化
    // printf(
    //     "[%-30s]:  min=%8.3f ms, max=%8.3f ms, avg=%8.3f "
    //     "ms\n",
    //     t->name(), minT * 1000, maxT * 1000,
    //     avgT * 1000 / num_timing_iterations);
}

后面就是具体的测试了，展示两个测试结果：

本机 MacOS 的运行结果，我前面发布的 Assignment 1 的 wsl2 的测试结果。

不知道什么缘故，MacOS 跑得很奇怪，不能过的测试的情况，甚至不需要改的串行，打不过参照版本。

记得把对应的 ref 可执行文件设置执行权限

MacOS 的测试结果：

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
# python3 ../tests/run_test_harness.py

# MacOS
runtasks_ref
Darwin arm64
================================================================================
Running task system grading harness... (11 total tests)
  - Detected CPU with 14 execution contexts
  - Task system configured to use at most 14 threads
================================================================================
================================================================================
Executing test: super_super_light...
Reference binary: ./runtasks_ref_osx_arm
Results for: super_super_light
                                        STUDENT   REFERENCE   PERF?
[Serial]                                3.333     3.388       0.98  (OK)
[Parallel + Always Spawn]               40.791    41.765      0.98  (OK)
[Parallel + Thread Pool + Spin]         30.702    60.015      0.51  (OK)
[Parallel + Thread Pool + Sleep]        23.379    23.475      1.00  (OK)
================================================================================
Executing test: super_light...
Reference binary: ./runtasks_ref_osx_arm
Results for: super_light
                                        STUDENT   REFERENCE   PERF?
[Serial]                                13.892    18.94       0.73  (OK)
[Parallel + Always Spawn]               49.262    50.518      0.98  (OK)
[Parallel + Thread Pool + Spin]         34.876    85.981      0.41  (OK)
[Parallel + Thread Pool + Sleep]        32.64     31.334      1.04  (OK)
================================================================================
Executing test: ping_pong_equal...
Reference binary: ./runtasks_ref_osx_arm
Results for: ping_pong_equal
                                        STUDENT   REFERENCE   PERF?
[Serial]                                233.014   372.162     0.63  (OK)
[Parallel + Always Spawn]               70.801    89.837      0.79  (OK)
[Parallel + Thread Pool + Spin]         55.278    118.816     0.47  (OK)
[Parallel + Thread Pool + Sleep]        49.07     64.635      0.76  (OK)
================================================================================
Executing test: ping_pong_unequal...
Reference binary: ./runtasks_ref_osx_arm
Results for: ping_pong_unequal
                                        STUDENT   REFERENCE   PERF?
[Serial]                                687.359   529.064     1.30  (NOT OK)
[Parallel + Always Spawn]               112.08    96.883      1.16  (OK)
[Parallel + Thread Pool + Spin]         109.983   132.2       0.83  (OK)
[Parallel + Thread Pool + Sleep]        94.275    72.262      1.30  (NOT OK)
================================================================================
Executing test: recursive_fibonacci...
Reference binary: ./runtasks_ref_osx_arm
Results for: recursive_fibonacci
                                        STUDENT   REFERENCE   PERF?
[Serial]                                917.397   908.294     1.01  (OK)
[Parallel + Always Spawn]               88.143    87.136      1.01  (OK)
[Parallel + Thread Pool + Spin]         93.761    91.151      1.03  (OK)
[Parallel + Thread Pool + Sleep]        90.891    87.237      1.04  (OK)
================================================================================
Executing test: math_operations_in_tight_for_loop...
Reference binary: ./runtasks_ref_osx_arm
Results for: math_operations_in_tight_for_loop
                                        STUDENT   REFERENCE   PERF?
[Serial]                                206.775   208.574     0.99  (OK)
[Parallel + Always Spawn]               247.204   248.615     0.99  (OK)
[Parallel + Thread Pool + Spin]         142.73    337.597     0.42  (OK)
[Parallel + Thread Pool + Sleep]        115.278   104.963     1.10  (OK)
================================================================================
Executing test: math_operations_in_tight_for_loop_fewer_tasks...
Reference binary: ./runtasks_ref_osx_arm
Results for: math_operations_in_tight_for_loop_fewer_tasks
                                        STUDENT   REFERENCE   PERF?
[Serial]                                206.505   208.375     0.99  (OK)
[Parallel + Always Spawn]               236.613   236.781     1.00  (OK)
[Parallel + Thread Pool + Spin]         152.883   317.297     0.48  (OK)
[Parallel + Thread Pool + Sleep]        107.491   93.697      1.15  (OK)
================================================================================
Executing test: math_operations_in_tight_for_loop_fan_in...
Reference binary: ./runtasks_ref_osx_arm
Results for: math_operations_in_tight_for_loop_fan_in
                                        STUDENT   REFERENCE   PERF?
[Serial]                                106.303   107.268     0.99  (OK)
[Parallel + Always Spawn]               38.578    39.553      0.98  (OK)
[Parallel + Thread Pool + Spin]         29.772    59.795      0.50  (OK)
[Parallel + Thread Pool + Sleep]        25.858    23.483      1.10  (OK)
================================================================================
Executing test: math_operations_in_tight_for_loop_reduction_tree...
Reference binary: ./runtasks_ref_osx_arm
Results for: math_operations_in_tight_for_loop_reduction_tree
                                        STUDENT   REFERENCE   PERF?
[Serial]                                106.5     107.555     0.99  (OK)
[Parallel + Always Spawn]               17.227    16.92       1.02  (OK)
[Parallel + Thread Pool + Spin]         15.236    18.473      0.82  (OK)
[Parallel + Thread Pool + Sleep]        13.976    12.774      1.09  (OK)
================================================================================
Executing test: spin_between_run_calls...
Reference binary: ./runtasks_ref_osx_arm
Results for: spin_between_run_calls
                                        STUDENT   REFERENCE   PERF?
[Serial]                                325.933   329.414     0.99  (OK)
[Parallel + Always Spawn]               168.387   166.579     1.01  (OK)
[Parallel + Thread Pool + Spin]         172.841   172.559     1.00  (OK)
[Parallel + Thread Pool + Sleep]        170.135   166.414     1.02  (OK)
================================================================================
Executing test: mandelbrot_chunked...
Reference binary: ./runtasks_ref_osx_arm
Results for: mandelbrot_chunked
                                        STUDENT   REFERENCE   PERF?
[Serial]                                234.344   238.415     0.98  (OK)
[Parallel + Always Spawn]               23.441    23.949      0.98  (OK)
[Parallel + Thread Pool + Spin]         24.577    24.065      1.02  (OK)
[Parallel + Thread Pool + Sleep]        23.558    23.893      0.99  (OK)
================================================================================
Overall performance results
[Serial]                                : Perf did not pass all tests
[Parallel + Always Spawn]               : All passed Perf
[Parallel + Thread Pool + Spin]         : All passed Perf
[Parallel + Thread Pool + Sleep]        : Perf did not pass all tests

接下来是 wsl2 的测试结果：

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
# python3 ../tests/run_test_harness.py

# Linux (wsl2)
runtasks_ref
Linux x86_64
================================================================================
Running task system grading harness... (11 total tests)
  - Detected CPU with 16 execution contexts
  - Task system configured to use at most 16 threads
================================================================================
================================================================================
Executing test: super_super_light...
Reference binary: ./runtasks_ref_linux
Results for: super_super_light
                                        STUDENT   REFERENCE   PERF?
[Serial]                                8.802     13.128      0.67  (OK)
[Parallel + Always Spawn]               605.881   598.953     1.01  (OK)
[Parallel + Thread Pool + Spin]         17.418    29.269      0.60  (OK)
[Parallel + Thread Pool + Sleep]        130.41    128.733     1.01  (OK)
================================================================================
Executing test: super_light...
Reference binary: ./runtasks_ref_linux
Results for: super_light
                                        STUDENT   REFERENCE   PERF?
[Serial]                                77.868    82.437      0.94  (OK)
[Parallel + Always Spawn]               600.781   603.958     0.99  (OK)
[Parallel + Thread Pool + Spin]         23.272    35.303      0.66  (OK)
[Parallel + Thread Pool + Sleep]        121.364   121.066     1.00  (OK)
================================================================================
Executing test: ping_pong_equal...
Reference binary: ./runtasks_ref_linux
Results for: ping_pong_equal
                                        STUDENT   REFERENCE   PERF?
[Serial]                                1258.518  1328.074    0.95  (OK)
[Parallel + Always Spawn]               644.312   653.419     0.99  (OK)
[Parallel + Thread Pool + Spin]         252.352   280.218     0.90  (OK)
[Parallel + Thread Pool + Sleep]        252.865   278.068     0.91  (OK)
================================================================================
Executing test: ping_pong_unequal...
Reference binary: ./runtasks_ref_linux
Results for: ping_pong_unequal
                                        STUDENT   REFERENCE   PERF?
[Serial]                                1835.189  1872.283    0.98  (OK)
[Parallel + Always Spawn]               678.557   682.423     0.99  (OK)
[Parallel + Thread Pool + Spin]         293.994   320.018     0.92  (OK)
[Parallel + Thread Pool + Sleep]        300.234   312.32      0.96  (OK)
================================================================================
Executing test: recursive_fibonacci...
Reference binary: ./runtasks_ref_linux
Results for: recursive_fibonacci
                                        STUDENT   REFERENCE   PERF?
[Serial]                                1053.251  1858.459    0.57  (OK)
[Parallel + Always Spawn]               163.893   227.547     0.72  (OK)
[Parallel + Thread Pool + Spin]         161.371   238.919     0.68  (OK)
[Parallel + Thread Pool + Sleep]        156.074   207.127     0.75  (OK)
================================================================================
Executing test: math_operations_in_tight_for_loop...
Reference binary: ./runtasks_ref_linux
Results for: math_operations_in_tight_for_loop
                                        STUDENT   REFERENCE   PERF?
[Serial]                                668.082   666.432     1.00  (OK)
[Parallel + Always Spawn]               3089.146  3064.197    1.01  (OK)
[Parallel + Thread Pool + Spin]         213.058   250.838     0.85  (OK)
[Parallel + Thread Pool + Sleep]        607.31    605.516     1.00  (OK)
================================================================================
Executing test: math_operations_in_tight_for_loop_fewer_tasks...
Reference binary: ./runtasks_ref_linux
Results for: math_operations_in_tight_for_loop_fewer_tasks
                                        STUDENT   REFERENCE   PERF?
[Serial]                                668.517   666.362     1.00  (OK)
[Parallel + Always Spawn]               3067.389  3094.792    0.99  (OK)
[Parallel + Thread Pool + Spin]         209.684   243.559     0.86  (OK)
[Parallel + Thread Pool + Sleep]        608.357   611.346     1.00  (OK)
================================================================================
Executing test: math_operations_in_tight_for_loop_fan_in...
Reference binary: ./runtasks_ref_linux
Results for: math_operations_in_tight_for_loop_fan_in
                                        STUDENT   REFERENCE   PERF?
[Serial]                                343.895   345.364     1.00  (OK)
[Parallel + Always Spawn]               400.428   400.808     1.00  (OK)
[Parallel + Thread Pool + Spin]         62.778    76.579      0.82  (OK)
[Parallel + Thread Pool + Sleep]        86.475    99.433      0.87  (OK)
================================================================================
Executing test: math_operations_in_tight_for_loop_reduction_tree...
Reference binary: ./runtasks_ref_linux
Results for: math_operations_in_tight_for_loop_reduction_tree
                                        STUDENT   REFERENCE   PERF?
[Serial]                                341.52    341.368     1.00  (OK)
[Parallel + Always Spawn]               114.191   115.154     0.99  (OK)
[Parallel + Thread Pool + Spin]         51.682    56.073      0.92  (OK)
[Parallel + Thread Pool + Sleep]        59.162    59.922      0.99  (OK)
================================================================================
Executing test: spin_between_run_calls...
Reference binary: ./runtasks_ref_linux
Results for: spin_between_run_calls
                                        STUDENT   REFERENCE   PERF?
[Serial]                                370.866   656.866     0.56  (OK)
[Parallel + Always Spawn]               193.432   337.548     0.57  (OK)
[Parallel + Thread Pool + Spin]         327.29    474.147     0.69  (OK)
[Parallel + Thread Pool + Sleep]        187.028   333.137     0.56  (OK)
================================================================================
Executing test: mandelbrot_chunked...
Reference binary: ./runtasks_ref_linux
Results for: mandelbrot_chunked
                                        STUDENT   REFERENCE   PERF?
[Serial]                                431.728   429.047     1.01  (OK)
[Parallel + Always Spawn]               32.047    32.035      1.00  (OK)
[Parallel + Thread Pool + Spin]         33.911    33.334      1.02  (OK)
[Parallel + Thread Pool + Sleep]        33.27     31.475      1.06  (OK)
================================================================================
Overall performance results
[Serial]                                : All passed Perf
[Parallel + Always Spawn]               : All passed Perf
[Parallel + Thread Pool + Spin]         : All passed Perf
[Parallel + Thread Pool + Sleep]        : All passed Perf

Part B: Supporting Execution of Task Graphs

实现异步的任务图。

并发这一部分还是挺折磨的，虽然其实就几项东西，但常常写挂，又要调试（我是输出调试了大部分都保留在代码中，有大佬说可以试试 C++ 有的日志库，可能可以节省点精力），特别是在修了一个地方后，发现修假了，只是奇妙正确了，然后继续修；改写法之后，之前改对又变成改错的。

所以，这一部分实现，再确定正确性没有什么问题之后，性能部分可能确实有点犯懒跑路了，咕咕。

因为有很多类任务，而前面的实现，有一系列参数都是给一类任务完成使用的。

所以，我们能够想到为一类任务，创建一个专属的结构体；对于最后的析构和同步，则是另一部分参数。

前期主要用 simple_test_async 在后面大部分时候使用 super_light_async 查问题。

说思路感觉有些繁杂，没有理出一条简洁的思考线路来，简单提一下遇到的几个坑吧。

关于测试的，记得最后用异步的测试去测异步啊（x

映射的 TaskInfo 和 _task_executable_list 的 TaskInfo 的信息同步更新。

有些正确性问题，默认的 run_test_harness.py 并不能测出来，建议增加一下全都测一遍正确性。

（简单应该就在该文件中的 LIST_OF_TESTS 增加些测试字段就好）

  1
  2
  3
  4
  5
  6
  7
  8
  9
 10
 11
 12
 13
 14
 15
 16
 17
 18
 19
 20
 21
 22
 23
 24
 25
 26
 27
 28
 29
 30
 31
 32
 33
 34
 35
 36
 37
 38
 39
 40
 41
 42
 43
 44
 45
 46
 47
 48
 49
 50
 51
 52
 53
 54
 55
 56
 57
 58
 59
 60
 61
 62
 63
 64
 65
 66
 67
 68
 69
 70
 71
 72
 73
 74
 75
 76
 77
 78
 79
 80
 81
 82
 83
 84
 85
 86
 87
 88
 89
 90
 91
 92
 93
 94
 95
 96
 97
 98
 99
100
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
117
118
119
120
121
122
123
124
125
126
127
128
129
130
131
132
133
134
135
136
137
138
139
140
141
142
143
144
145
146
147
148
149
150
151
152
153
154
155
156
157
158
159
160
161
162
163
164
165
166
167
168
169
170
// tasksys.h

#include <algorithm>
#include <condition_variable>
#include <list>
#include <mutex>
#include <thread>
#include <unordered_map>
#include <vector>

class TaskSystemParallelThreadPoolSleeping : public ITaskSystem {
private:
    struct TaskInfo {  // 具体任务的完成情况
        TaskID _idx;   // 任务编号
        IRunnable* runnable;
        int _num_total_tasks;
        int _current_task_id;  // id 用于同类任务的执行进度标识
        int _num_done_tasks;
        int _num_deps;                     // 依赖的任务数
        std::vector<TaskID> _successores;  // 后继
    };
    int _num_threads;
    std::thread* _threads_worker;
    bool _end;
    // 当前最大的任务类编号, idx 用于不同任务种类
    int _current_task_idx;
    // 任务编号到具体任务完成情况的映射
    // 一开始是指还有依赖的任务的映射，后面改错时变成单纯的映射关系了
    // 这里就懒得改变量名了
    std::unordered_map<TaskID, TaskInfo> _task_waiting_map;
    // 已经可以执行的任务列表
    std::list<TaskInfo*> _task_executable_list;
    std::mutex *_mtx, *_mtx_done;
    std::condition_variable *_cv, *_cv_done;
}

// tasksys.cpp

TaskSystemParallelThreadPoolSleeping::TaskSystemParallelThreadPoolSleeping(
    int num_threads)
    : ITaskSystem(num_threads),
      _num_threads(num_threads),
      _threads_worker(new std::thread[num_threads]),
      _end(false),
      _current_task_idx(0),
      _mtx(new std::mutex),
      _mtx_done(new std::mutex),
      _cv(new std::condition_variable),
      _cv_done(new std::condition_variable) {
    auto work = [&]() {
        while (true) {
            std::unique_lock<std::mutex> lk(*_mtx);
            _cv->wait(lk,
                      [&]() { return !_task_executable_list.empty() || _end; });
            if (_end) return;

            auto iter_iter_task = std::find_if(
                _task_executable_list.begin(), _task_executable_list.end(),
                [](const TaskInfo* t) {
                    return t->_current_task_id < t->_num_total_tasks;
                });
            if (iter_iter_task == _task_executable_list.end()) {
                // cv
                // all_work_dispatched
                continue;
            }

            TaskInfo* iter_task = *iter_iter_task;

            int id_cur = iter_task->_current_task_id++;
            lk.unlock();

            iter_task->runnable->runTask(id_cur, iter_task->_num_total_tasks);

            lk.lock();
            bool is_empty = false;
            iter_task->_num_done_tasks++;
            // printf("task_idx: %d -> num_done_tasks: %d\n", iter_task->_idx,
            //        iter_task->_num_done_tasks);
            if (iter_task->_num_done_tasks == iter_task->_num_total_tasks) {
                for (TaskID successor : iter_task->_successores) {
                    // printf("task_idx: %d -> successor: %d\n",
                    // iter_task->_idx,
                    //        successor);
                    if (--_task_waiting_map[successor]._num_deps == 0) {
                        _task_executable_list.push_back(
                            (TaskInfo*)&_task_waiting_map[successor]);
                        // 原本指还有依赖的任务，所以erase，但是现在不是（x
                        // _task_waiting_map.erase(successor);
                    }
                }
                // printf("done task_idx: %d\n", iter_task->_idx);
                _task_executable_list.erase(iter_iter_task);
                // printf("_task_executable_list size: %d\n",
                //        _task_executable_list.size());
                is_empty = _task_executable_list.empty();
            }
            lk.unlock();
            if (is_empty) {
                _cv_done->notify_one();
            }
        }
    };
    for (int i = 0; i < _num_threads; i++) {
        _threads_worker[i] = std::thread(work);
    }
}

TaskSystemParallelThreadPoolSleeping::~TaskSystemParallelThreadPoolSleeping() {
    // sync(); // 可能没啥必要（？
    _mtx->lock();
    _end = true;
    _mtx->unlock();
    _cv->notify_all();
    for (int i = 0; i < _num_threads; i++) {
        _threads_worker[i].join();
    }
    delete[] _threads_worker;
    delete _mtx;
    delete _mtx_done;
    delete _cv;
    delete _cv_done;
}

void TaskSystemParallelThreadPoolSleeping::run(IRunnable* runnable,
                                               int num_total_tasks) {
    runAsyncWithDeps(runnable, num_total_tasks, {});
    sync();
}

TaskID TaskSystemParallelThreadPoolSleeping::runAsyncWithDeps(
    IRunnable* runnable, int num_total_tasks, const std::vector<TaskID>& deps) {
    std::unique_lock<std::mutex> lk(*_mtx);
    TaskID task_idx = _current_task_idx++;
    // printf("begin run async %d, num_total_tasks: %d\n", task_idx,
    //        num_total_tasks);
    // for (auto dep : deps) {
    //     printf("%d depends on %d\n", task_idx, dep);
    // }
    TaskInfo task{task_idx, runnable, num_total_tasks, 0, 0, 0, {}};
    for (TaskID dep : deps) {
        // auto it = _task_waiting_map.find(dep);
        // if (it != _task_waiting_map.end()) {
        //     // printf("%d depends on %d\n", task_idx, dep);
        //     it->second._successores.push_back(task_idx);
        //     task._num_deps++;
        // }
        // 因为修改了 _task_waiting_map 的含义，需要检测下是否还是需要考虑的依赖
        auto& t = _task_waiting_map[dep];
        if (t._num_done_tasks < t._num_total_tasks) {
            t._successores.push_back(task_idx);
            task._num_deps++;
        }
    }
    // printf("num_deps: %d\n", task._num_deps);
    _task_waiting_map[task_idx] = task;
    if (task._num_deps == 0) {
        _task_executable_list.push_back(
            (TaskInfo*)&_task_waiting_map[task_idx]);
    }
    lk.unlock();
    _cv->notify_all();
    return task_idx;
}

void TaskSystemParallelThreadPoolSleeping::sync() {
    std::unique_lock<std::mutex> lk(*_mtx);
    _cv_done->wait(lk, [&]() { return _task_executable_list.empty(); });
    return;
}

最后也是都列一下两次都测试结果

测试

原本看 MacOS 上的结果以为性能菜爆了，wsl2 上看起来很正常啊，~~可以安心逃了啊~~
